System Setup
Line Title
Line
Number
Description
Action
Overlap Distance Press ENTER to change16
CapstanAG has coined the term “Cat Whiskers” to describe this feature. Each nozzle has
five imaginary cat whiskers by which it checks and marks the overlap map. There is a
whisker in front, behind, right, left, and center. The center whisker marks the map as being
sprayed. The other four whiskers are for checking if the nozzle needs to be turned off at an
already sprayed area. The overlap distance refers to the distance that these four whiskers
are from the center whisker. The PinPoint
™
II map is in one-meter-squares, so it is advised
to set this at a minimum of 40 in (1 meter).
Rate Sync Mode Press ENTER to change17
Rate Sync
™
changes the nozzle duty cycle based on the vehicle speed obtained from the
GPS receiver.
Rate Sync Average Press ENTER to change18
The Rate Sync
™
average represents how often the rate sync samples the speed from GPS.
PinPoint
™
II has a 10hz GPS requirement, so the speed is sampled 10 times per second or
once every 0.1 seconds. Higher values cause the system to react slower.
Rate Sync Max Ground Speed Press ENTER to change19
Enter the approximate speed that will allow the system to reach a 100% duty cycle based
on the current spray tip size being used.
Units Press ENTER to change20
Select the desired units of choice: US or SI units.
Baud Rate21
This shows the GPS baud rate that is detected by the system. 19,200 to 115,200.
Revision Information Press ENTER to change and then YES22
The revision information stores all hardware items by CAN address and shows the current
version of all hardware and software items on the system. This includes the CapView,
Gateway hub, and VCM software versions.
Language Press ENTER to change23
Select the desired language: English or Portuguese
Previous Error List Press ENTER to change24
This displays the 50 most recent errors.
Advanced Settings Press ENTER to see the menu25
Additional settings menu
©
