System Setup
Do the Nozzle Setup Procedure
1. Press the NOZZLE SETUP button.
Nozzle Setup is to set up each individual nozzle for:
• Rank
• Flow Value—Used to adjust nozzle flow for fence row and wheel track
• Nozzle Size—Used to adjust to match tip size
• Valve Size—15.5 for standard valve assemblies and 24.0 for high flow valve assemblies
• Auxiliary and Soft Boom Attachment
Each individual nozzles can be tested, or the identity confirmed.
The Nozzle Setup screen includes set up for:
• Fence Rows
• Wheel Track
• Dust Control Nozzles
• Soft Booms for Non-conventional Nozzle Groupings
Individual nozzle tip sizes can be changed on the Nozzle Setup screen. Default nozzles are
indicated with a “D.” Always make sure that the tip size is correct on the Nozzle Setup screen.
Four different default nozzle sizes can be set up, one for each PRESET button. You can save the
profile to a number by simply pressing the number buttons #1, #2, #3, or #4.
From the operation screen, any of the four preset nozzle setups can be selected by pressing and
holding the desired PRESET button for approximately five seconds.
The nozzle setup should change.
2. Use the arrow buttons to highlight the desired information to change.
3. Press the ENTER button.
4. Change the information.
5. Press the ENTER button.
©
