System Setup
Line Title
Line
Number
Description
Action
Flowmeter Error Limit Press ENTER to change.33
The flowmeter error limit ranges from Disabled to 50%. Flow % higher than the chosen %
will cause a fault message and an alarm.
Flowmeter Error Press ENTER to change.34
The flowmeter error shows the real-time % difference between the flowmeter and the
calculated flow.
Low Flow Hold Flow Rate35
The low flow hold flow rate is set to Disabled except on John Deere R Series sprayers;
this must be set to 10 GPM.
Rate Sync Test Speed Press ENTER to change.36
The Rate Sync
™
test speed is not used at this time.
Minimum Valves ON Press ENTER to change.37
The minimum valves on defaults to 1. Reduces the over application of chemical product
with chemical injection. Used for chemical injection systems (not N-Ject
™
).
Navigation IMU Press ENTER to change.38
This feature must be enabled to allow quicker response time to the headings.
Note: The PSI NAV Commander Module must be mounted correctly for this feature to
function correctly.
Pressure Command Press ENTER to change.39
Enable this feature if the system is using a Raven PC2 Node to get the correct rate control
for the system.
GPS Lag Time Press ENTER to change.40
This is used to correct the delayed GPS signal from the antenna.
Factory Reset
Press ENTER and then YES to change.
41
The factory reset will reset all setups in the entire system to the default settings. The
factory reset is required when repairing or replacing parts of the system. Make sure that
you have recorded the setups you prefer before resetting. With a properly prepared “cheat
sheet,” a factory reset only takes a few minutes.
Contact Information42
Selecting this line will open up a page with the CapstanAG toll-free phone number,
website, and a QRC code that will direct you to the website.
©
