Cardinal 225D SmartCell - Specifications

8200-0753-0M Rev A  225D Weight Digital Indicator
2
SPECIFICATIONS
Power Requirements:
100 to 240 VAC (50/60 Hz) at 0.4A Max.
Enclosure Type:
Stainless Steel wall or desk-mount
Enclosure Size:
10 7/8"W x 8 3/16"H x 3 1/8"D
(276mm W x 208mm H x 79mm D)
Weight:
9.2lbs (4.2kg) Size and Weight DOES NOT include Gimbal
Operating Environment:
Temperature: 14 to 104 ºF (-10 to +40 ºC)
Humidity: 90% non-condensing (maximum)
Display:
240 x 64 (5” x 1.33”/127 x 34mm) Graphics LCD w/ LED Backlight
Division Value:
Commercial: 1, 2, or 5 x 10, 1, 0.1, 0.01, 0.001 and 0.0001
Non-commercial: 0 to 99
Sensitivity:
NON-COMMERCIAL
NTEP
CANADA
OIML
0.15 uV/e
0.3uV/e (Class III/IIIL)
0.3uV/e (Class III/IIIHD)
0.7 uV/e (Class III)
Scale Divisions:
NON-COMMERCIAL
NTEP
CANADA
OIML
100 to 240,000
100 to 10,000 (Class III/IIIL)
100 to 10,000 (Class III/IIIHD)
100 to 10,000 (Class III)
Internal Resolution:
1 part in 16,777,216
Tare Capacity:
Six Digits (999,999)
Sample Rate:
1 to 100 samples per second, selectable
Auto Zero Range:
0.5 or 1 through 9 divisions
Weighing Units:
Tons, Pounds, Ounces, Tonnes ”Metric Tons”, Kilograms, Grams,
Keypad:
Membrane type with 60 color-coded keys
Standard I/O:
4 ea Serial I/O Ports configured as:
3 ea bi-directional RS-232 ports or 3 ea 20mA output-only ports
1 ea bi-directional 20mA port
1 ea output only RS-232/20mA port
8 ea Remote Isolated Inputs
16 ea Remote Isolated Outputs
225DLC Connections:
Homerun Cable - 5 position spring cage clamp (24 to 16ga wire)
Ethernet Port for iSite – (1) RJ-45
USB-B port – Used for firmware updates to 225DLC card
Internal Connections:
(1) 16 pin DIL
Homerun Cable Length:
Consult Digital Load Cell cable chart. Consult factory for other
requirements.
Number of Load Cells:
20 digital load cell with 15V power at scale
36 digital load cells with 24V power at scale
