PD100
Unpacking
Remove the scale base, display, hardware pack and other components from the shipping
carton. After removing from the carton, check for any damage that may have taken place during
shipment. Keep and use the original carton and packing material for return shipment if it should
become necessary. The purchaser is responsible for filing all claims for any damages or loss
incurred during transit. Remove all plastic wrapping, foam fillers and cardboard material from
the scale base, display and other components. You should have the following components:
(1) Scale Base
(1) Remote Display
(1) Wall Bracket “A”
(includes four (4) feet for desk or table mounting)
(1) Wall Bracket “B”
(1) Hardware Pack, containing:
(2) M3.0x25 Screws and plastic wall anchors
M3.0x25 Screw
Plastic Wall Anchor
Assembly
The PD100 does not require any assembly. After installing batteries, the scale is ready for
operation.
Quick Start
Although it is recommended that you read this manual before attempting to operate the scale,
this section is included to provide a condensed set of instructions on installing and using the
scale. At a minimum, please make certain you read all of the caution and warning statements.
Step 1. Place the scale on the floor and then place the display at a convenient distance
from the scale base.
Step 2. Turn the scale over on the floor and then locate the battery access cover on the
bottom of the scale.
Step 3. Remove the cover, install six (6) “AA” size batteries
1
and then replace the cover.
Step 4. Turn the scale over to the normal operating position and make sure it is level.
Step 5. Press the ON/OFF key to turn the scale on.
2
Step 6. When the display is showing 0.0, have to patient step on the scale.
Step 7. Wait a few seconds for the weight to display and then read the patient’s weight.
Step 8. Patient may now step off scale.
Step 9. Press the ON/OFF key to turn the scale off.
1
See page 16 for detailed instructions on installing the batteries.
2
For complete Operation and Setup instructions, refer to pages 18 to 26.
