Carel Macroplus - I;O Range

14
Refer to the following figure to get the number of inputs/outputs of each board.
ANALOGUE
INPUTS
DIGITAL
INPUTS
ANALOGUE
OUTPUTS
DIGITAL
OUTPUTS
Small Not
Expandable
3 13 3 12+1
Small Expandable
6 13 3 12+1
Large
6 24 4 16+1
Additional
8 8 4 8
Carel reserves the possibility to modify or change its products without prior notice
- I/O RANGE
