Carel pCO1 User Manual

Modular Standard HP Chiller for Carel driver
Carel code +030221236- Rel. 1.0 dated 7 July 2003
17
Driver 2 superheat set-point during defrost. operation F9 M/S 6,0 2.0 to 50.0 °C
Driver 2 dead band during defrost. operation
F9 M/S 0 0 to 9.9 °C
Driver 2 superheat set-point during chiller operation Fa M/S 2,5 0.0 to 99.9
Driver 1 integral time during chiller operation Fa M/S 25 0 to 999 seconds
Driver 1 derivative time during chiller operation Fa M/S 2,0 0.0 to 99.9 seconds
Driver 1 proportional gain during heat pump
operation
Fb M/S 2,5 0.0 to 99.9
Driver 1 integral time during heat pump operation Fb M/S 25 0 to 999 seconds
Driver 1 derivative time during heat pump operation Fb M/S 2,0 0.0 to 99.9 seconds
Driver 2 proportional gain during defrost. operation Fc M/S 2,5 0.0 to 99.9
Driver 1 integral time during defrost. operation Fc M/S 25 0 to 999 seconds
Driver 1 derivative time during defrost. operation Fc M/S 2,0 0.0 to 99.9 seconds
Driver 2 proportional gain during chiller operation Fd M/S 2,5 0.0 to 99.9
Driver 2 integral time during chiller operation Fd M/S 25 0 to 999 seconds
Driver 2 derivative time during chiller operation Fd M/S 2,0 0.0 to 99.9 seconds
Driver 2 proportional gain during heat pump
operation
Fe M/S 2,5 0.0 to 99.9
Driver 2 integral time during heat pump operation Fe M/S 25 0 to 999 seconds
Driver 2 derivative time during heat pump operation Fe M/S 2,0 0.0 to 99.9 seconds
Driver 2 proportional gain during defrost. operation Ff M/S 2,5 0.0 to 99.9
Driver 2 integral time during defrost. operation Ff M/S 25 0 to 999 seconds
Driver 2 derivative time during defrost. operation Ff M/S 2,0 0.0 to 99.9 seconds
Threshold for protection of low super heat driver 1
during chiller operation
Fg M/S 4,0 -4.0 to 10.0 °C
Integral time for protection of low super heat driver 1
during chiller operation
Fg M/S 1,0 0 to 25.5 seconds
Threshold for protection of low super heat driver 1
heat pump operation
Fh M/S 4,0 -4.0 to 10.0 °C
Threshold integral time for protection of low super
heat driver 1 heat pump operation
Fh M/S 1,0 0 to 25.5 seconds
Threshold for protection of low super heat driver 1
during defrost. operation
Fi M/S 4,0 -4.0 to 10.0 °C
Integral time for protection of low super heat driver 1
during defrost operation
Fi M/S 1,0 0 to 25.5 seconds
Threshold for protection of low super heat driver 2
during chiller operation
Fj M/S 4,0 -4.0 to 10.0 °C
Threshold integral time for protection of low super
heat driver 2 heat pump operation
Fj M/S 1,0 0 to 25.5 seconds
Threshold for protection of low super heat driver 2
heat pump operation
Fk M/S 4,0 -4.0 to 10.0 °C
Threshold integral time for protection of low super
heat driver 2 heat pump operation
Fk M/S 1,0 0 to 25.5 seconds
Threshold for protection of low super heat driver 2
during defrost. operation
Fl M/S 4,0 -4.0 to 10.0 °C
Threshold integral time for protection of low super
heat driver 2 defrost. operation
Fl M/S 1,0 0 to 25.5 seconds
Threshold for LOP protection during chiller
operation
Fm M/S -40,0 -70.0 to 50.0 °C
Integral time of threshold for LOP protection during
chiller operation
Fm M/S 4,0 0 to 25.5 seconds
Threshold for LOP protection during heat pump
operation
Fn M/S -40,0 -70.0 to 50.0 °C
Integral time of threshold for LOP protection during
heat pump operation
Fn M/S 4,0 0 to 25.5 seconds
Threshold for LOP protection during defrost.
operation
Fo M/S -40,0 -70.0 to 50.0 °C
Integral time of threshold for LOP protection during
defrost. operation
Fo M/S 4,0 0 to 25.5 seconds
Delayed start MOP protection during chiller
operation
Fp M/S 30 0 to 500 seconds
Threshold for MOP protection during chiller
operation
Fp M/S 40,0 -50.0 to 99.9 °C
Integral time of threshold for MOP protection during
chiller operation
Fp M/S 4,0 0 to 25.5 seconds
Delayed start MOP protection during heat pump
operation
Fq M/S 30 0 to 500 seconds
Threshold for MOP protection during heat pump
operation
Fq M/S 40,0 -50.0 to 99.9 °C
Integral time of MOP protection during heat pump
operation
Fq M/S 4,0 0 to 25.5 seconds
Delayed start MOP protection during chiller
operation
Fr M/S 30 0 to 500 seconds
Threshold for MOP protection during chiller
operation
Fr M/S 40,0 -50.0 to 99.9 °C
Integral time of threshold for MOP protection during
chiller operation
Fr M/S 4,0 0 to 25.5 seconds
