Parameter Def Min Max U.M. R/W Description Applicable for
Can’t be modi ed if
drive is in RUN
PM AC
vect.
AC
V/f
8 Reverse speed enable 0 0 1 - R/W Enables the run command also in anti-clockwise
direction: 0 = disabled; 1 = enabled
YYYN
9 Speed derating mode 0 0 10 °C R/W The function allows to automatically reduce the speed
depending on the temperature of the drive. If enabled,
the value 3 is recommended (see par. 6.3).
0 = function disabled
YYYN
10 Skip frequency: set 0 0 5000
(500.0Hz)
0.1Hz R/W Sets the prohibited frequencies interval set. See par. 6.1 Y Y Y N
11 Skip frequency: band 0 0 5000
(500.0Hz)
0.1Hz R/W Sets the prohibited frequencies interval band. See par. 6.1 Y Y Y N
12 Speed pro le: frequency 1 0 0 5000
(500.0Hz)
0.1Hz R/W Frequency 1 of the speed pro le Y Y Y N
13 Speed pro le: frequency 2 0 0 5000
(500.0Hz)
0.1Hz R/W Frequency 2 of the speed pro le Y Y Y N
14 Speed pro le: frequency 3 0 0 5000
(500.0Hz)
0.1Hz R/W Frequency 3 of the speed pro le Y Y Y N
15 Speed pro le: acceleration 1 60
(6.0Hz/s)
0 500
(50.0Hz/s)
0.1Hz/s R/W Acceleration 1 of the speed pro le Y Y Y N
16 Speed pro le: acceleration 2 60
(6.0Hz/s)
0 500
(50.0Hz/s)
0.1Hz/s R/W Acceleration 2 of the speed pro le Y Y Y N
17 Speed pro le: acceleration 3 60
(6.0Hz/s)
0 500
(50.0Hz/s)
0.1Hz/s R/W Acceleration 3 of the speed pro le Y Y Y N
18 Speed pro le: acceleration 4
60
(6.0Hz/s)
0 500
(50.0Hz/s)
0.1Hz/s R/W Acceleration 4 of the speed pro le Y Y Y N
19 Speed pro le: delay 1 0 0 600 s R/W Delay 1 of the speed pro le Y Y Y N
20 Speed pro le: delay 2 0 0 600 s R/W Delay 2 of the speed pro le Y Y Y N
21 Speed pro le: delay 3 0 0 600 s R/W Delay 3 of the speed pro le Y Y Y N
22 Speed pro le: execution
method (2 bit parameter)
3 0 3 - R/W See par. 5.6
bit meaning 0/1
0 delay execution always/only once at every start-up
1 force frequency 2 no/at start-up
YYYN
23 Speed pro le: deceleration 60(
6.0Hz/s)
0 500
(50.0Hz/s)
0.1Hz/s R/W Set the frequency deceleration Y Y Y N
24 Switching frequency 0 0 2 - R/W Sets the switching frequency of the IGBT. See par. 6.2.
0 = 4kHz; 1 = 6kHz; 2 = 8kHz
YYYN
25 Switching frequency
derating
0 0 1 - R/W The function allows to automatically decrease the PWM
switching frequency on the basis of drive temperature:
0 = disabled; 1 = enabled
YYYN
26 Relay con guration 0 0 8 - R/W Selects the event associated to closure of the relay contact
0 drive in alarm
1 fan running
2 drive overtemper. alarm
3 motor overtemp. alarm
4 motor overload alarm
5 overvoltage alarm
6 undervoltage alarm
7 speed derating in progress
8 motor running
YYYN
27 Motor overtemperature
alarm (PTC) enable
0 0 1 - R/W Enables the motor overtemperature alarm, which occurs
if the PTC input sees a resistance of > 2600 ohm at its
ends for the time set at the “Motor overtemperature
alarm delay” parameter
0 = disabled; 1 = enabled
YYYN
28 Motor overtemperature
alarm delay
0 0 600 s R/W Sets the time after which the “Motor overtemperature”
alarm occurs
YYYN
29 Data communication fault
timeout
0 0 600 s R/W Sets the time after which the “Data communication
fault” alarm occurs if the communication with the
Master is interrupted (only if the motor is running)
0 = alarm disabled
YYYN
30 Data communication
baudrate
1 0 1 - R/W Sets the Modbus® communication baudrate. The
modi ed value becomes e ective only after a reset or
successive switch-on of the drive.
0 = 9600 bit/s; 1 = 19200 bit/s
YYYN
31 Data communication parity
and stopbit
0 0 2 - R/W Set the data communication parity and stop bit for
communication. The modi ed value becomes e ective
only after a reset or successive switch-on of the drive.
0 = none (2 stopbit);
1 = even (1 stopbit);
2 = odd (1 stopbit)
YYYN
32 Base address 1 1 232 - R/W Sets the drive base address. The drive network address
is included in the “Base address”…”Base address” +15
interval, according to the position of the dip-switches.
The modi ed value becomes e ective only after a reset
or successive switch-on of the drive.
YYYN
