Carel Power+ User Manual

ENG
“Power+” +0300050EN - rel. 2.3 - 08.06.2012 28
Mod. add.
Parameter Def Min Max U.M. R/W Description Applicable for
Can’t be modi ed if
drive is in RUN
PM AC
vect.
AC
V/f
33 Stop mode 1 0 1 - R/W Sets the drive stop mode, following a stop command.
0 = ramp; 1 = coast
YYYN
34 Flying restart 0 0 1 - R/W Enables speed hitching, whenever the RUN command
takes place with motor rotating.
0 = disabled; 1 = enabled
NYY N
35 V/f boost voltage 0 0 250 (25.0%) 0.1%
Motor base
voltage
R/W Sets the voltage applied at frequency 0. See par. 5.10. N N Y Y
36 V/f frequency adjustment 0 0 1000
(100.0%)
0.1%
Motor base
frequency
R/W Sets the frequency adjustment to adapt the V/f curve. N N Y Y
37 V/f voltage adjustment 0 0 1000
(100.0%)
0.1%
Motor base
voltage
R/W Sets the voltage adjustment to adapt the V/f curve. N N Y Y
38 RESERVED (DO NOT MODIFY) 0 - - - R/W - - - -
39 RESERVED (DO NOT MODIFY) 0 - - - R/W - - - -
40 RESERVED (DO NOT MODIFY) - - - - R/W - - - -
41 RESERVED (DO NOT MODIFY) - - - - R/W - - - -
42 RESERVED (DO NOT MODIFY) - - - - R/W - - - -
43 RESERVED (DO NOT MODIFY) 0 - - - R/W - - - -
44 RESERVED (DO NOT MODIFY) 0 - - - R/W - - - -
45 Motor magnetizing current 0 0 Motor
rated
current
0.1A R/W Sets the motor magnetizing current N Y N N
46 Stator resistance 0 0 Depend.
on the
model (*)
m R/W Sets the stator resistance
(*) Max
PSD0***2*0**: 33000 (30.)
PSD0***4*0**: 38500 (38.5)
YYNN
47 Rotor resistance 0 0 Depend.
on the
model (*)
m R/W Sets the rotor resistance
(*) Max
PSD0***2*0**: 33000 (30.)
PSD0***4*0**: 38500 (38.5)
NYNN
48 Stator inductance/Ld 0 0 Depend.
on the
model (*)
0.1mH R/W Sets the motor stator inductance (Ld component
for motors with permanent magnets (PM), Ls for
asynchronous motors)
(*) Max
PSD0***2*0**: 5280 (528.0mH)
PSD0***4*0**: 6130 (613.0mH)
YYNN
49 Leakage factor 0 0 250
(0.25)
- R/W Sets the motor dispersion factor (0=stator and rotor
perfectly coupled. Set at 100 (=0.1)
NYNN
50 Lq inductance 0 0 Depend.
on the
model (*)
0.1mH R/W Sets the inductance component Lq per for the motor
with permanent magnets (PM)
(*) Max
PSD0***2*0**: 5280 (528.0mH)
PSD0***4*0**: 6130 (613.0mH)
YNNN
51 Magnetizing time 100
(0.1s)
0 30000
(30.000s)
ms R/W Sets the application time of the “Starting current” or of
the “Voltage boost”
YYY Y
52 RESERVED (DO NOT MODIFY) 0 0 1 - R/W - - - -
53 Regeneration current limit 1000
(100.0%)
0 2000
(200.0%)
0.1%
Motor rated
current
R/W Sets the regeneration current limit. Set the “Maximum
motor current” value
YYNN
54 Overvoltage control current
limit
100
(10.0%)
0 2000
(200.0%)
0.1%
Motor
rated
current
R/W Sets the current limit to use for the prevention of
overvoltage. In the case of overvoltage, the drive
accelerates the motor slightly to prevent the alarm.
YYNN
55 Speed loop: Kp 250
(25.0%)
1
(0.1%)
2000
(200.0%)
0.1% R/W Expressed in tenths of percentage of the unit gain Y Y N N
56 Speed loop: Ti 500
(0.5s)
1
(0.001s)
1000
(1s)
ms R/W Y Y N N
57 Starting current 200
(20.0%)
0 1000
(100.0%)
0.1% R/W The current applied at start-up depends on the type of
motor:
Permanent magnets
Motor
Asynchronous motor with
vector control
Starting current *
Rated current
(100% + starting current)*
Magnetizing current
YYNN
58 Max frequency for starting
current
0 0 1000
(100.0%)
0.1%
Motor base
frequency
R/W Sets the frequency up to which the current applied at
start-up is applied
YYNN
59 RESERVED (DO NOT MODIFY) 0 - - - R/W - - - -
Tab. 7.a

Carel Power+ Specifications

General

Protection degree	IP20
Rated Power	0.75-630kW
Communication	Modbus RTU
Operating Temperature	-10°C to +50°C
Cooling method	Forced ventilation
Ambient temperature range	-10°C to +50°C
Relative humidity	< 95% non-condensing
Storage temperature range	-20...+70 °C (-4...+158 °F)
