Maintenance and Troubleshooting
2011-03-31 9G3886_en 3-7
Film Cartridge
Film
Cartridge
State
Display Screen Web Portal Description
Failed Power symbol is yellow
Pause and Calibrate symbols are off
Film count is replaced by dashes
Failed An error has occurred that affects
normal operation. This film
cartridge is currently not usable.
Reinsert the cartridge. If error
reoccurs, insert a new film
cartridge.
Calibrating Power symbol is green and flashing
Pause symbol is on
Calibrate symbol is blue and flashing
Calibrating A calibration is in progress for the
film cartridge.
Film cartridge is
empty
Power symbol is yellow
Pause and Calibrate symbols are off
Film count is flashing "0"
Empty and/or sheet
count of 0
The film cartridge is inserted but the
sheet count is 0. Insert a new
cartridge.
Manual mode Status code: 002
Power symbol is green
Calibrate symbol is yellow
AIQC Off (with
normal tray
information)
The film in this cartridge does not
meet AIQC standards. However, the
laser imager prints if ready.
Invalid film
cartridge
Power symbol is yellow
Pause and Calibrate symbols are off
Film count is replaced by dashes
Invalid Film Tray There is a film cartridge in the film
supply but it does not contain a
liner/RF tag. Install a new film
cartridge.
Ready Power symbol is green
Calibrate symbol is on
Normal Tray Info The film cartridge is ready for use.
Requires
calibration
Power symbol is yellow
Calibrate symbol is on
Requires
Calibration
The film cartridge must be
calibrated before the laser imager
can print. See “Calibrating the laser
imager for the installed film” on
page 2-9.
Film cartridge is
not detected
Power symbol is yellow
Pause and Calibrate symbols are off
Film count is blank
No Film Tray The film cartridge is not fully
inserted in the laser imager. Insert
the cartridge.
Not ready Various Not Ready When the conditions are corrected,
the laser imager can print.
