5.9 - Short circuit withstand current
Short-circuit withstand current (TN system
(1)
)
30RB-RBP 170R 190R 210R 230R 270R 310R 340R 380R 410R
Rated short-circuit withstand currents
Rated short time (1s) current - Icw kA e󰀨 5,5 8,5 8,5 8,5 8,5 20 20 20 20
Rated peak current - Ipk kA pk 154 330 330 330 330 330 330 330 330
Value with upstream electrical protection
(1)
Rated conditional short circuit current Icc kA e󰀨 50 50 50 50 50 50 50 50 50
Associated protection
NSX160N
/ =S=
NSX250N
/ =S=
NSX250N
/ =S=
NSX250N
/ =S=
NSX250N
/ =S=
NSX250N
/ =S=
NSX400N
/ =S=
NSX400N
/ =S=
NSX400N
/ =S=
Associated protection
TM160D /
LV430840
TM200D /
LV431831
TM200D /
LV431831
TM250D /
LV431831
TM250D /
LV431831
TM250D /
LV431831
Micrologic
2,3 400 A /
LV432693
Micrologic
2,3 400 A /
LV432693
Micrologic
2,3 400 A /
LV432693
30RB-RBP 450R 480R 550R 610R 670R 720R 770R 820R 870R 950R
Rated short-circuit withstand
currents
Rated short time (1s) current - Icw kA e󰀨 20 20 20 20 20 20 35 35 35 35
Rated peak current - Ipk kA pk 330 330 330 330 330 330 330 330 330 330
Value with upstream electrical protection
(1)
Rated conditional short circuit current Icc kA e󰀨 50 50 50 50 50 50 50 50 50 50
Associated protection
NSX400N
/ =S=
NSX630N
/ =S=
NSX630N
/ =S=
NSX630N
/ =S=
NSX630N
/ =S=
NSX630N
/ =S=
NS800 /
=S=
NS800 /
=S=
NS800 /
=S=
NS800 /
=S=
Associated protection
Micrologic
2,3 400 A /
LV432693
Micrologic
2,3 630 A /
LV432893
Micrologic
2,3 630 A /
LV432893
Micrologic
2,3 630 A /
LV432893
Micrologic
2,3 630 A /
LV432893
Micrologic
2,3 630 A /
LV432893
Micrologic
5,0 800 A
/34426
Micrologic
5,0 800 A
/34426
Micrologic
5,0 800 A
/34426
Micrologic
5,0 800 A
/34426
30RQ-RQP 165R 180R 210R 230R 270R 310R
Rated short-circuit withstand currents
Rated short time (1s) current - Icw kA e󰀨 5,5 8,5 8,5 8,5 8,5 20
Rated peak current - Ipk kA pk 154 330 330 330 330 330
Value with upstream electrical protection
(1)
Rated conditional short circuit current Icc kA e󰀨 50 50 50 50 50 50
Associated protection
NSX160N /
=S=
NSX250N /
=S=
NSX250N /
=S=
NSX250N /
=S=
NSX250N /
=S=
NSX400N /
=S=
Associated protection
TM160D /
LV430840
TM200D /
LV431831
TM250D /
LV431831
TM250D /
LV431831
TM250D /
LV431831
Micrologic
2,3 400 A /
LV432693
30RQ-RQP 330R 370R 400R 430R 470R 520R
Rated short-circuit withstand currents
Rated short time (1s) current - Icw kA e󰀨 20 20 20 20 20 20
Rated peak current - Ipk kA pk 330 330 330 330 330 330
Value with upstream electrical protection
(1)
Rated conditional short circuit current Icc kA e󰀨 50 50 50 50 50 50
Associated protection
NSX400N /
=S=
NSX400N /
=S=
NSX400N /
=S=
NSX400N /
=S=
NSX630N /
=S=
NSX630N /
=S=
Associated protection
Micrologic
2,3 400 A /
LV432693
Micrologic
2,3 400 A /
LV432693
Micrologic
2,3 400 A /
LV432693
Micrologic
2,3 400 A /
LV432693
Micrologic
2,3 630 A /
LV432893
Micrologic
2,3 630 A /
LV432893
(1) If another current limitation protection device is used, its time-current and thermal constraint (I²t) trip characteristics must be at least equivalent to those of the recommended
protection.
Note: The short-circuit withstand current capability values above have been established for the TN system.
IT system: The short circuit holding current values given above for the TN system are not valid for IT; modications are
required.
