Low pressure pumps
Single pumps
Sizes 170R - 380R
Available static pressure, kPa
Water ow rate, l/s
B
C
D
E
F
1 30RB-RBP 170R - 230R
2 30RB-RBP 270R
3 30RB-RBP 310R
4 30RB-RBP 340R
5 30RB-RBP 380R
Sizes 410R - 550R
Available static pressure, kPa
Water ow rate, l/s
G
IJ
H
6 30RB-RBP 410R
7 30RB-RBP 450R
8 30RB-RBP 480R
9 30RB-RBP 550R
Dual pumps
Sizes 170R - 410R
Available static pressure, kPa
Water ow rate, l/s
20
40
60
80
100
120
140
160
180
200
220
240
0,0 5,0 10,0 15,0 20, 0 25,0
B
C
D
E
F
G
H
1 30RB-RBP 170R - 190R
2 30RB-RBP 210R - 230R
3 30RB-RBP 270R
4 30RB-RBP 310R
5 30RB-RBP 340R
6 30RB-RBP 380R
7 30RB-RBP 410R
Sizes 450R - 550R
Available static pressure, kPa
Water ow rate, l/s
20
40
60
80
100
120
140
160
180
200
220
240
260
280
5,0 10,0 15,0 20,0 25,0 30,0
IK
J
8 30RB-RBP 450R
9 30RB-RBP 480R
10 30RB-RBP 550R
