Appendix A: RTU Open Points/Properties
58 RTU Open
Status
Navigation: i-Vu / Field Assistant:
BACview:
Properties
>
Equipment
>
Status
HOME > STATUS
Point Name/Description
Range
System Mode
R: – The controller's current operating status. Disabled
Test
Run
Operating Mode
R: – The controller's current operating mode. Off
Fan Only
Economizer
Cooling
Heating
Dehumidification
Test
Shutdown
Unocc Free Cooling (NTFC)
Supply Fan Status
– The current fan status if an input is configured for
Fan Status
R: . Off/Running
Space Temperature
- Prime Variable
R: – The space temperature value currently used for
control.
-56 to 245°F
Supply Air Temperature
R: – The current supply air temperature. -56 to 245°F
Outdoor Air Temperature
R: – The outdoor air temperature value used for control. -56 to 245°F
Space Relative Humidity
– The current space relative humidity if
Configuration
>
Unit
Configuration
>
Input 1
(or
2
)
Function
is set to
Space RH Sensor
R:
.
0 to 100%rh
Indoor Air CO2
– The current indoor air CO
2
concentration if the
Configuration
>
Unit
Configuration
>
Input 1
(or
2
)
Function
is set to
IAQ Sensor
R:
.
0 to 5000ppm
Outdoor Air CO2
– The current outdoor air CO
2
concentration if the
Configuration
>
Unit
Configuration
>
Input 1
(or
2
)
Function
is set to
OAQ Sensor
R:
.
0 to 5000ppm
Economizer Output
R: – The current economizer output with respect to the outdoor air
damper (if equipped).
0 to 100% Open
Appendix A: RTU Open Points/Properties
