RS – Multi-Stage, I-280
Centrifugal Pump 280 – 16.03.EN
2
F. PARTS INVENTORY GUIDE. To avoid
unnecessary delays for maintenance, spare parts
should be readily available, purchase before and keep in
stock, for normal service. Most conditions will be
covered if this manual is followed. For every one to
three pumps, stock one spare set consisting of items
listed in Table 19, Recommended Spare Parts. Part
numbers correspond to Figures 11, 12 and 13.
G. PARTS ORDERING. When ordering replacement
parts, please specify:
Serial number of pump (located on nameplate)
Part name (located on parts list)
Quantity of parts needed
Carver Pump Company may ship an interchangeable
part that is not identical in appearance or symbol. This is
done only if the part has been improved. Examine parts
carefully upon delivery before questioning factory or
company representative. Never return parts to the
factory without authorization from Carver Pump
Company.
If an impeller is ordered, specify diameter across blade
tips. Be sure diameter was NOT trimmed further than
diameter shown on Carver Pump Company records.
If a driver or driver parts are ordered, specify name of
manufacturer and all other data found on the driver
nameplate.
II. SAFETY.
A. SAFETY PRECAUTIONS. The manual is designed
to provide adequate instructions for the safe and
efficient installation, operation, or maintenance of the
pump. Failure or neglect to properly install, operate, or
maintain the pump may result in personal injury,
property damage, or unnecessary damage to the pump.
This manual must be read and understood both by the
installing personnel and the responsible trained
personnel/operators prior to installation and operation,
and it must always be kept close to the location of the
pumping unit for easy access.
B. SUMMARY OF SAFETY MARKING. The safety
instructions contained in this manual follow specific
ATEX safety marking where non-observance of the
instruction will cause a hazard is specially marked with
the symbol:
This symbol indicates explosive
atmosphere marking according to ATEX. It is
used in safety instructions where non-
compliance in the hazardous area would cause
the risk of an explosion.
General hazard sign to ISO 7000 - 0434.
The word "Caution" is used to introduce safety
instructions whose non-observance may lead to damage
to the machine and its functions.
Instructions attached directly to the machine, e.g.
Arrow indicating the direction of rotation
Markings for fluid connections must always be
complied with and be kept in a perfectly legible
condition at all times.
Observe all notes, caution or danger tags attached to
the equipment or included in this manual.
C. PRODUCTS USED IN POTENTIALLY EXPLOSIVE
ATMOSPHERES
Measures are required to:
Avoid excess temperature
Prevent buildup of explosive mixtures
Prevent the generation of sparks
Prevent leakages
Maintain the pump to avoid hazard
The following instructions for pumps and pump units
when installed in potentially explosive atmospheres
must be followed to help ensure explosion protection.
Both electrical and non-electrical equipment must meet
the requirements of European Directive 94/9/EC.
D. SCOPE OF COMPLIANCE.
Use equipment only in the zone for which
it is appropriate. Always check that the driver,
drive coupling assembly, seal and pump
equipment are suitably rated and/or certified for
the classification of the specific atmosphere in
which they are to be installed.
Where Carver Pump has supplied only the bare shaft
pump, the Ex rating applies only to the pump. The party
responsible for assembling the pump set shall select the
