2. Barcode Description
EX) Barcode Description = EAN13-1
3. Barcode Type
Reference following table.
EX) Barcode Type = 1. EAN-13
Type of Barcode
No. Type Description
1 EAN-13 13digit
2 EAN13A5 13digit + 5digit
3 EAN-8 8 digit
4 I20F5 2~24 digit
5 UPCA 12 digit
6 UPC-13 13 digit
7 CODE39
8 CODE93
9 CODE128
10 CODABAR
Alphanumeric character, Format âTâ, prints out the name
of PLU.
4. Enter Barcode Form
You can select from a list of Barcode
types or you can create your own custom
format
Refer to following table.
EX) Barcode Form = 1. Change
DDIIIIIPPPPPC to GGIIIIIVPPPPC
Barcode format symbol
No Symbol Description
1I item code
2NPLU number
3P
price
4V
price check digit (It is created automatically)
5Uunit price
6W
weight
7Q
quantity
8Ddepartment
9Ggroup
10 K
country code (For future)
11 A
ticket counter (Only for ticket)
12 B
scale transaction counter
13 C total barcode check sum (It is created automatically)
14 F PLU prefix character
15 T text character
16 R transaction counter for each PLU
17 L clerk number
18 X traceability number
19 Y
slaughter house number
20 Z
cutting hall number
21 E
born in country number
22 H
bred in country number
23 M
bar string
The following defines the format characters for Barcode Formats :
(Example
EAN13 )
Form No. Format Form No. Format
0 User Defined Barcode DIIIIIPPPPPPC
1 DDIIIIIPPPPPC DIIIIIIPPPPPC
2 DDIIIIPPPPPPC
