Menu-4410
This function is check for communication status. when weight is changed or hunted by
extenal noise.
(100% = Good, 80% = Not bad, under 75% = Bad)
Menu-4420
Function Diagnostic of DLC
Display Part Meaning
Set Range
(1 ~ 10)
Set Value : XX
Initial Value : 1
Choose the number that you want to diagnose
EX _ 1 = Currently connected to the DLC’S ID is set to ‘1’
EX _ 8 = Currently connected to the DLC’S ID is set to ‘8’’
Status Diagnosis list Result
AD Stable NG (Data : 5)
Overload OK (Data : 120000)
Temperature
OK (Data : 20) = It means 20℃
Loadcell Over Voltage OK (Data : 5.1V)
Power Over Voltage OK (Data : 10.9V)
Note 1. If weighing has some problem, use this function.
