Menu-2207
Function Set Com1 Output mode
Display Part Meaning
ᆷ 1_No Data
Output
Data is not transmitted
ᆷ 2_Transmit When
Print Key is Pushed
Transmitted only if the print key is pushed
ᆷ 3_Transmit in Both
Stable/Unstable
Cases
Transmitted in both stable/unstable cases (Stream Mode)
ᆷ 4_Transmit Only if
Weight Is Stable
Transmitted only if the weight is stable
ᆷ 5_Command
Type 1
Command Type 1
ᆷ 6_Command
Type 2
Command Type 2
ᆷ 7_Command
Type 3
Command Type 3
ᆷ 8_Transmit upon
Completion Signal
Transmitted only upon completion signal
Set Range
(1 ~ 9)
ᆷ 9_Modbus
Modbus protocol
Note 1. See Appendices 2, 3, 4 for command types
Menu-2208
Function Com2 Port Setting(RS232, Print)
Display Part Meaning
ᆷ 1_Data_8 / Stop_1 /
Parity_none
Data Bit 8, Stop Bit 1, Parity Bit : None
ᆷ 2_Data_7 / Stop_1 /
Parity_even
Data Bit 7, Stop Bit 1, Parity Bit : Even
ᆷ 3_Data_7 / Stop_1 /
Parity_odd
Data Bit 7, Stop Bit 1, Parity Bit : Odd
ᆷ 4_Data_7 / Stop_2 /
Parity_odd
Data Bit 7, Stop Bit 2, Parity Bit: Odd
ᆷ 5_Data_8 / Stop_1 /
Parity_even
Data Bit 8, Stop Bit 1, Parity Bit: Even
Set Range
(1 ~ 6)
ᆷ 6_Data_8 / Stop_1 /
Parity_odd
Data Bit 8, Stop Bit 1, Parity Bit: Odd
61
