CAS CI-600D Series - Page 61

Menu-2209
Function Set COM2 Baud Rate
Display Part Meaning
ᆷ 1_1,200 bps
1,200 bps
ᆷ 2_2,400 bps
2,400 bps
ᆷ 3_4,800 bps
4,800 bps
ᆷ 4_9,600 bps
9,600 bps
ᆷ 5_19,200 bps
19,200 bps
ᆷ 6_38,400 bps
38,400 bps
ᆷ 7_57,600 bps
57,600 bps
Set Range
(1 ~ 8)
ᆷ8_115,200 bps
115,200 bps
Menu-2210
Function Set Com2 Out Data
Display Part Meaning
ᆷ 1_Displaed
Value
Displayed value is transmitted
ᆷ 2_Gross Weight
Gross Weight is transmitted
Set Range
(1 ~ 3)
ᆷ 3_Net Weight
Net weight is transmitted
Menu-2211
Function Set COM2 Output Format
Display Part Meaning
ᆷ 1_CAS 22
22 byte of CAS
ᆷ 2_ CAS10
10 byte of CAS
ᆷ 3_AND18
18 byte Format(AND, FINE)
Set Range
(1 ~ 4)
ᆷ 4_CAS 22
Relay status
22 byte of CAS with relay status
Note 1. See <Appendix 1> for communication format
