41
4.5 Printer Hardware
No.
Sub-menus Description
1 Print Mode
Select label, ticket, continuous label mode.
2 Label / Ticket
Size
Lable mode: “Width(60)”, “Height(40)” and “Gap length(2)”
Ticket mode: “Width(60)”, “Feed(20)” and “End Margin(5)”
Continous Label: “Width(60)”, “Feed(40)” and “End Margin(2)”
* ( ) are default value.
3 Sensor
Calibration
Enter the “Gap(128)” and “Peel(128)” values for printing sensor
calibration.
* The values in ( ) are default.
* If you press “TEST” key, Gap and Peel values are adjusted
automatically.
* In case of Ticket mode, Gap value is not saved.
4 Sensor & Motor
Setting Peel-off sensor, Rewind Motor, Label Paper type.
5 Print Intensity
Set the extent of intensity of label (ticket) printed.
6 Adjust Feed
Length
Set adjusting values of feed length.
This value can be from -200 to +200. You can change sign(+,-) by
pressing ZERO key.
+ value will print higher than THP.
* Pressing “TEST” key automatically feeds to adjust the feed length.
7 Label Pre-print
You can set preprint length.
8 Printer Initialize
You can reset printer.
4.5.1 Print Mode (Menu Code 8310)
(Calibration MENU -> 3. Printer Hardware -> 1. Print Mode)
Press “1” to get into “PRINT MODE.”
You can select “0” for Label mode, “1” for Ticket mode or “2” for Continuous Label mode.
Press “PRINT” to save current selection.
4.5.2 Label/Ticket Size (Menu Code 8320)
(Calibration MENU -> 3. Printer Hardware -> 2. Label/Ticket Size)
You can input “Width,” “Height,” “Gap Length” of label manually.
“TEST” key will automatically measures current label.
* Case of ticket mode “TICKET SIZE” will display and “TEST” key will not function.
