5.1 Platform Safety Overload Adjustment
1) Turn power off and remove power cord
2) Remove tray from scale
3) Remove calibration cealing
4) Remove the upper case
5) Put 150% of max weight on platform rear right. This point Allen- bolt should not be
touched
6) Adjust Allen- bolt just about to touch the bottom frame
7) Contiune the procedure on each corner
