CAL 3
FUNCTION : Setting Weight In Span CALIBRATION
RANGE ---> 1 ~ Maximum capacity of CAL1
KEY LED DISPLAY DESCRIPTION
SET key : store and move into
next menu
NUMERIC key : set value change
CLR key : input the point, initial
value.
L= 5000
L= 500
5000 kg
500 kg
REF 1. The setting weight shall be within the range of 10 % ~ 100 % of maximum weight.
CAL 4
FUNCTION :Zero Calibration
KEY LED DISPLAY DESCRIPTION
SET key : Zero calibration
UnLOAd
Unload the tray and press SET
The program moves into Span
calibration automatically.
REF 1. If Zero calibration is done without any error, SUCCESS message is displayed
and program moves into CAL 5 automatically.
REF 2. If the zero value is too low, high check message (CH 14) is displayed.
CAL 5
FUNCTION :Span Calibration
KEY LED DISPLAY DESCRIPTION
SET key : Span calibration
LOAd
Load the weight which was set in
CAL 3 and press SET key.
REF 1. If Span calibration is done without any error, Good message is displayed.
REF 2. If the span is low, check message (CH 13) is displayed.
