(2) Calibration Mode
CH 11
Reason ▣
The resolution is set to be exceeded the limit 1/10,000.
Solution ☞
lower the resolution. modify the allowed weight in CAL1 or modify the
division in CAL2 so that the resolution should be below 1/10,000.
CH 12
Reason ▣
The weight for span calibration is set to be lower than 10% of the maximum
capacity of the scale, or exceeded 100% of the maximum capacity of the scale.
Solution ☞
Set the weight for span calibration to be within the maximum capacity of
the scale in CAL1.
CH 13
Reason ▣
Load cell output is too small(large) at SPAN calibration.
Solution ☞
Setting of current resolution is not possible due to the error in load
cell. proceed calibration again with less resolution.
CH 14
Reason ▣
Load cell output is too small(large) at ZERO calibration.
Solution ☞
Check whether the ;platform empty.
Proceed calibration again after checking in A/D TEST mode.
