Cascadia PM Series User Manual

7929 SW Burns Way Phone: 503 344-5085
Suite F
Wilsonville, OR sales@cascadiamotion.com
1/14/2021 RMS PM Hardware User Manual 14 of 54
H
RTD1N
RTD1 Negative
J
GND
GND
Encoder GND
K
HALL C
Hall Input C
L
HALL A
Hall Input A
For use with certain motors that
support Hall encoders.
M
ENCZ
Encoder Channel Z input
(Index)
N
ENC A
Encoder Channel A input
Quadrature encoder used with
Induction Motors
P
XDCR_PWR
+5V @ 80mA max
Encoder Power
R
RTD2P
RTD2 Positive
Can be either PT100 or PT1000
S
RTD2N
RTD2 Negative
T
GND
Resolver Shield GND
U
AIN2
Analog Input 2
Used with certain motors for
temperature sensing.
V
AIN4
Analog Input 4
Used with certain motors for
temperature sensing.
W
AGND
Analog Ground
Ground reference for use with
AIN2 and AIN4
X
XDCR_PWR
+5V @ 80mA max
For use with pull-up resistor.
Y
HALL B
Hall Input B
Z
GND
AA or a
ENCB
Encoder Channel B input
AB or b
AIN2PU
Pull-up resistor on AIN2
If connected to XDCR_PWR will
enable a 1K ohm pull-up resistor
to be connected to AIN2.
AC or c
AIN4PU
Pull-up resistor on AIN4
If connected to XDCR_PWR will
enable a 1K ohm pull-up resistor
to be connected to AIN4.
J2 Connections
Pin #
Pin Name
Description
Notes
