1/14/2021 RMS PM Hardware User Manual 37 of 54
3.7.1 Controller 12V Power Wiring
This circuit can be configured in two different ways:
NOTE: RM100 can only use the Simple ON/OFF Configuration.
(a) Simple ON/OFF Configuration
In this configuration an external switch or controller is responsible for control of the 12V
power. Thus the inverter will have a less controlled shutdown process as power could
be removed while it is actively controlling the motor. When using this configuration set
the EEPROM parameter Key_Switch_Mode_EEPROM to 0.
Controller 12V Power Wiring - Configuration 0
+12 V Power
Switched ON when Inverter ON
BATT+
GND
12 V Return / Vehicle Chassis
