CASE CONSTRUCTION CX130B - WORK UNIT; Backhoe Attachment Dimensions; Digging Dimensions

Issued 06-15
1002-20
Work Unit
Model..................................................................................................................................................Backhoe attachment
Components / dimensions / working dimensions
CX130B (Standard boom)
CX130B
Standard arm
2500 mm
(98.42 in)
Short arm
2110 mm
(83.07 in)
Long arm
3010 mm
(118.50 in)
Arm (dipper) length
3086 mm
(121.50 in)
2690 mm
(105.91 in)
3605 mm
(141.93 in)
Boom length (Standard boom spec.)
4630 mm
182.28 in
Bucket radius
1200 mm
47.24 in
Bucket wrist action 178°
Maximum digging radius
8310 mm
327.16 in
7690 mm
302.75 in
8770 mm
345.27 in
Maximum digging radius at ground line
8170 mm
321.65 in
7810 mm
307.48 in
8640 mm
340.16 in
Maximum digging depth
5540 mm
218.11 in
5150 mm
202.75 in
6050 mm
238.19 in
Maximum vertical straight wall digging depth
4950 mm
194.88 in
4600 mm
181.10 in
5350 mm
210.63 in
Maximum digging height
8770 mm
345.27 in
8550 mm
336.61 in
9050 mm
356.30 in
Maximum dump height
6390 mm
251.57 in
6170 mm
242.91 in
6680 mm
262.99 in
Minimum swing radius at front
2340 mm
92.13 in
2360 mm
92.91 in
2660 mm
104.72 in
Height for minimum swing radius at front
6560 mm
258.27 in
6560 mm
258.27 in
6590 mm
259.45 in
