DISTRIBUTION SYSTEMS - HIGH-FLOW HYDRAULIC POWER SYSTEM
Hydraulic pump - Remove (A.16.A.20 - F.10.A.10)
435
1. For removal of the High Flow Pump, refer to the
following procedure. Hydraulic pump - Remove
(A.10.A.20 - F.10.A.10)
bs04d018 1
435 High Flow Hydraulic Installation
1. High flow pump 4. High flow valve 7. High flow tube
2. Tandem hydrostatic pump
5. High flo w accumula tor 8. High flow pump to valve hose
connection
3. Loader control valve
6. High flow tube 9. High flow oil c ooler
1 04/05/2005
A.16.A / 14
