Case 445CT - Page 135

DISTRIBUTION SYSTEMS - ELECTRICA L POWE R SYSTEM
B9402124A 2
95 Ampere Alternator
1. Nut
8. Cover 15. Stator
22. Fla
t washer
2. Wash
er
9. Spacer 16. Screw
23. Nut
3. Retainer 10. Front bearing
17. Re
ctifier Bridge
24. Lock washer
4. Scr
ew
11. Bearing retainer 18. Insulator 25. Brush
5. Pulley 12. K ey
19. S hield
26. Voltage regulator and
brush holder
6. Fan 13. Rotor 20. Housing
27. Capacitor
7. Screw
14. R
ear bearing
21. Fi
ber washer
1 04/05/2005
A.30.A / 9
