Case 445CT - Page 148

DISTRIBUTION SYSTEMS - ELECTRICA L POWE R SYSTEM
Connector 23
amp_3-1437290-8 3
Cavity Circuit ID
Description
3
130C (R) To connector 2
9pinC
24
300H (R) From splice 1
2(Key"ON")
23
300G (R) From splice 1
2(Key"ON")
10
137A (R) From connec
tor 9 pin D (Key "ACC")
21
781A (P)
To connector 99 pin A
22
782A (P)
To connector 96 pin 86
7
641B (W)
To connector 8 pin H1
15
261B (W) To connect
or 8 pin G2
2
264B (Y) To connec
tor 8 pin G4
25
257B (Y) To connec
tor 8 pin G1
16
266B (Y)
To connector 8 pin J1
1
234B (Y)
To connector 8 pin F1
18
255B (Y)
To connector 8 pin E4
17
262B (Y) To conne
ctor 8 pin G3
19
124B (R
)
To connector 8 pin B4
20
200B (B
/W)
Clean g
round
Connector 29
291718a1 4
Cavity Circuit ID
Des
cription
1
266A (Y)
To c
onnector 8A p in J1
2
178F (B)
To g
round
Connector 30
245482c1 5
1 04/05/2005
A.30.A / 22
