Case 445CT - Page 157

DISTRIBUTION SYSTEMS - ELECTRICA L POWE R SYSTEM
Connector 122
291718a1 4
Cavity Circuit ID
Description
1
178BP (B)
To connector 124 pin A
2
546B (T)
From co nnector 123 pin B
Connector 124
cnh_style-24 5
Cavity Circuit ID
Descript
ion
A
178BS (B) From connector 122 pin 1 (Ground)
A
178BT (B) From connector 120 pin B (Ground)
B
535A (T)
From con
nector 72 pin A
B
535C (T)
From con
nector 120 pin A
