DISTRIBUTION SYSTEMS - ELECTRICA L POWE R SYSTEM
Connector 173
Cavity Circuit ID
Description
1
ET001E (R)
From connector 117A pin B
2
ET001F (B)
From connector 117A pin A
Connector 174
Cavity Circuit ID
Description
E
ET003A (P)
From co nnector 171 pin L
B
ET004A (Y)
From connector 171 pin M
C ET005A (O)
From co nnector 171 pin H
D
ET000A (B)
From connector 117A pin A
D
ET000B (B)
From co nnector 176 pin A
A
ET008A (LB)
From co nnector 172 pin B
F
ET009A (LB)
From air conditioner pressure switch
Connector 174A
Cavity Circuit ID
Description
E
ET003B (P)
To connector 175A pin E
B
ET004B (Y)
To connector 175A pin B
C ET005B (O) To connector 175A pin C
D
ET000G (B)
To connector 175A pin D
A
ET008B (LB)
To connector 175A pin A
F
ET009B (LB)
To connector 175A pin F
Connector 175
Cavity Circuit ID
Description
E
ET003C (P)
To connector 179 blower motor
B
ET004C (Y)
To connector 178 blower motor
C ET005C (O)
To connector 177 blower motor
D
ET000H (B)
From connector 180 blower motor
A
ET008C (LB)
To connector 181 thermostat
F
ET009C (LB)
From connector 182 thermostat
Connector 176
Cavity Circuit ID
Description
A
ET000B (B)
To connector 174 pin D
B
ET006A (Y)
From co nnector 170 pin 2
C ET001B (R)
From connector 117A pin A
1 04/05/2005
A.30.A / 36
