Case 445CT - Page 249

DISTRIBUTION SYSTEMS - HYDRAULIC COMMAND SYSTEM
Command Remote control lever - Exploded view (A.14.A.05.05 -
C.10.A.20)
435, 445, 445CT
bs04n027_1 1
Auxiliary Hydraulic Control System
(1) Pedal (5)Electrical Harnes s
(2) Pedal Loc k Leve r (6) Control Cable Assembly
(3) Linkage
(4) Electrical R ela y
1 04/05/2005
A.14.A / 3
