7-MAINTENANCE
Wheeltoe-inadjustment
Frontwheeltoe-in(2WS)
1.Thefrontwheeltoe-inispresetandadjustmentisnot
normallynecessary.
2.Periodicalchecksshouldbemadetoensurethecorrect
toe-inismaintained.
Adjustment
3.Placethemachineonalevelgroundpresentingnoel-
ementswhichcouldaffectadjustments.
4.Steerthewheelstothefront.
5.Measurethetoe-inbycheckingthetrackwidthbetween
thefrontofthewheelrim(1)andtherearofthewheel
rim(2)athubheight.
6.Thecorrecttoe-inmeasurementis0-6mm(0-24in).
LEEN12T0481AA2
7.Loosenthelocknut(3)oneachwheeltierodand
tightenthenut(4)withawrench,untilthecorrectwheel
toe-inisobtained.
8.Tightenthelocknut(3)andrecheckthetoe-in.
LEEN12T0482AA3
7-109
