7-MAINTENANCE
Adjustingscrew
1.Fouradjustingscrews(1)aremountedontheaxle,two
foreachside.
2.Thetworearscrewsareadjustableandsetthemini-
mumsteeringangle.
3.Thetwofrontscrewsareadjustableandmustbesetto
avoidthecontactofthetireswiththemachineincase
ofmaximumsteering.
4.T oadjust,slackenthelocknut(2)andtightenthescrew
(1)counterclockwisetoreducethesteeringangleofthe
wheelsorclockwisetoincreasethesteeringangle.
5.Tightenthelocknut(2)oncetheadjustmentiscom-
plete.
LEEN12T0483AA6
7-111
