OPERATING THE MACHINE
3-21
GEARBOX - GEAR CHANGE
According to the machine operation kind, you can
afford different operation types at gear change:
- 1st speed: left light on button (1) lit and right light
out;
- 2nd speed: left light out and right light on;
- automatic gearshift active: both lamps are out.
When the pedal (2) is activated, in the middle of the
lower section, the display shows the symbol of gear
engaged [the tortoise (A) = 1st speed or the hare (B)
= 2nd speed].
CREEP SPEED
The engagement/disengagement of the creep
speed is possible only at a travel speed lower than
20 km/h (12.43 mph). The creep speed can be
engaged/disengaged with button (3) (the right lamp
lights up at creep speed engagement). At the same
moment, on the display bottom right, the snail sym-
bol (C) appears. The speed of the relevant speed
engaged, lowers of about 80%.
