SECTION 4
4-38
QUICK COUPLER - GREASING
LOCKING CYLINDER
(1) = No. 1 grease nipple
(2) = No. 1 grease nipple
(3) = No. 1 grease nipple
LOCKING HOOK PIN
(4) = No. 1 grease nipple
