Case WX185 - Page 343

SECTION 8
8-2
OUTFIT WITH MONOBOOM
* = front blade, without bucket
G = tyres maximum width
O = machine maximum width
mm (in)
DipperABCDEFGH I LMNOPQRST
2000
(78.73)
2550
(100.39)
430
(16.92)
1230
(48.42)
1850
(72.83)
370
(14.5)
2923
(115.07)
2520
(99.21)
3050
(120.07)
3910
(153.93)
345
(13.58)
4445
(179.33)
930
(36.61)
2500
(98.42)
1070
(42.12)
7925
(312.00)
8065
(317.51)
1175
(46.25)
1010
(39.76)
2300
(90.55)
2550
(100.39)
430
(16.92)
1230
(48.42)
1850
(72.83)
370
(14.5)
3072
(120.94)
2520
(99.21)
3050
(120.07)
3910
(153.93)
345
(13.58)
4488
(176.69)
930
(36.61)
2500
(98.42)
1070
(42.12)
7968
(313.69)
8108
(319.21)
1175
(46.25)
1010
(39.76)
2600
(102.36)
2550
(100.39)
430
(16.92)
1230
(48.42)
1850
(72.83)
370
(14.5)
3201*
(126.02)
2520
(99.21)
3050
(120.07)
3910
(153.93)
345
(13.58)
4490*
(176.72)
930
(36.61)
2500
(98.42)
1070
(42.12)
7970*
(313.77)
8110*
(319.29)
1175
(46.25)
1010
(39.76)
Dipper (mm) (in)
Rear blade
(kg) (lb)
Rear stabilizers
(kg) (lb)
Front blade and rear
stabilizers (kg) (lb)
2000 (78.73) 13798 (30356) 14269 (31392) 14740 (32428)
2300 (90.55) 13848 (30466) 14319 (31502) 14790 (32538)
2600 (102.36) 13898 (30576) 14369 (31612) 14840 (32648)
