Case WX185 - Page 349

SECTION 8
8-8
OUTFIT WITH MONOBOOM
G = tyres maximum width
O = machine maximum width
mm (in)
DipperABCDEFGH I LMNOPQRST
2000
(78.73)
2650
(104.33)
450
(17.71)
1300
(51.18)
2150
(84.64)
320
(12.59)
2990
(117.71)
2520
(99.21)
3150
(124.01)
3900
(153.54)
365
(14.37)
5010
(197.24)
1010
(39.76)
2540
(99.99)
1040
(40.94)
8670
(341.33)
8700
(342.52)
1200
(47.24)
1060
(41.73)
2400
(94.48)
2650
(104.33)
450
(17.71)
1300
(51.18)
2150
(84.64)
320
(12.59)
2986
(117.55)
2520
(99.21)
3150
(124.01)
3900
(153.54)
365
(14.37)
5005
(197.04)
1010
(39.76)
2540
(99.99)
1040
(40.94)
8665
(341.14)
8695
(342.32)
1200
(47.24)
1060
(41.73)
2800
(113.38)
2650
(104.33)
450
(17.71)
1300
(51.18)
2150
(84.64)
320
(12.59)
3080
(121.25)
2520
(99.21)
3150
(124.01)
3900
(153.54)
365
(14.37)
5027
(197.91)
1010
(39.76)
2540
(99.99)
1040
(40.94)
8687
(342.00)
8717
(343.18)
1200
(47.24)
1060
(41.73)
Dipper (mm) (in)
Rear blade
(kg) (lb)
Rear stabilizers
(kg) (lb)
Front blade and
rear stabilizers
(kg) (lb)
Front and rear
stabilizers (kg) (lb)
2000 (78.73) 17866 (39305) 18416 (40515) 18996 (41791) 19456 (42803)
2400 (94.48) 17926 (39437) 18476 (40647) 19066 (41945) 19526 (42957)
2800 (110.23) 18016 (39635) 18576 (40867) 19156 (42143) 19616 (43155)
