2 Using the Setup Wizard
This section explains how to use the Setup Wizard to configure the EA-200 setup quickly
and easily simply by replying to questions as they appear.
If you need more control over specific sampling parameters, you should consider using the
Advanced Setup procedure on page 3-1.
k Setup Wizard Parameters
Setup Wizard lets you make changes to the following three EA-200 basic sampling
parameters using an interactive wizard format.
• Sensor (Select Sensor):
Specify a CASIO or VERNIER* sensor from a menu of choices.
*Vernier Software & Technology
• Total Sampling Time:
Specify a value within the range of 0.01 second to 30 days.
• Sampling Time Unit (Select Unit):
Specify seconds (sec), minutes (min), hours (hour), or days (day) as the time unit of the
value you input for the total sampling time (Total Sampling Time).
Note
For some sensors (EA-200 built-in microphone, Vernier PhotoGate, etc.), sampling
parameters are different from those shown above. The differences between sampling
parameters and setup procedures for each sensor are described in this section.
Setup Wizard Rules
Note the following rules whenever you use the Setup Wizard.
• The EA-200 sampling channel is CH1 or SONIC.
• The trigger for a Setup Wizard setup is always the w key.
2-1
Using the Setup Wizard

Casio fx-9750GII Specifications

General

Type	Graphing
Cover	-
Form factor	Desktop
Control type	Buttons
Product color	Blue
Digits	- digits
Display tilting	No
Display resolution	64 x 128 pixels
Display number of lines	8 lines
Display number of characters	21
Battery type	AAA
Power source	Battery
Auto power off	Yes
Number of batteries supported	4
Flash memory	0.061 MB
Storage media type	Flash
Symbolic notation	Square root
Conversion between	Decimal, Percent

Weight and Dimensions

Depth	180.5 mm
Width	87.5 mm
Height	21.3 mm
Weight	205 g
