Reference
EN-165
Audio Recorder Real-time recording and playback as audio data
Number of Songs 99 (files)
File Format WAV
*5
Maximum Recording Time When recording to USB flash drive: Approximately 25 minutes per file
When recording to the internal memory: Approximately 18 minutes
(total of all songs)
Recording Medium Internal memory (built-in flash memory) or USB flash drive
Arpeggiator 50 types
Metronome
Beat Bell Off, 1 to 9 (beats)
Drum Patterns 20 types
Tempo Range 20 to 255
Tempo Markings
9 types
Metronome Volume Level Adjustable
Registration Function 96 sets maximum (4 sets, 24 banks)
Pedals
PEDAL UNIT jack For connection of the included pedal unit or a separately available
pedal unit
Damper (continuously variable), sostenuto (off, on), soft (the included
pedal unit: off, half, on ; a separately available pedal unit: off, on)
EXPRESSION/
ASSIGNABLE jack
For connection of a commercially available expression pedal or a
separately available CASIO sustain pedal, selectable function
(expression, master volume, tempo, layer balance, damper (off, on),
sostenuto (off, on), soft (off, on), arpeggio hold (off, on), play/stop,
sequential recall of setup registrations)
Other Functions Auto Resume, Operation Lock
MIDI MIDI 16-channel multi-timbre receive; GM Level 1 standard
Pitch Bend Wheel Pitch bend range: 0 to 24 semitones
EX Buttons 2 (function-assignable buttons)
CONTROL Button 1 (function-assignable button)
Inputs/Outputs
PHONES jack Stereo standard phone jack (TRS phone) × 1,
Stereo mini phone jack (Mini TRS phone) × 1
Power 24V DC
LINE OUT R, L/MONO
jacks
Standard phone jack (TS phone) × 2 (Output impedance: 470 Ω,
Output voltage: 1.7 V (RMS) MAX)
MIC IN jack Standard phone jack (TS phone) (Input impedance: 3 kΩ,
Input voltage: 10 mV)
USB Ports Type A, Type B
EXPRESSION/
ASSIGNABLE jack
Stereo standard phone jack (TRS phone)
PEDAL UNIT jack Proprietary jack
