Casio Privia PX-S7000 User Manual

Operations Common to All Modes
EN-30
Use the settings list screen to select from many options for tones, functions, or specific settings. The
following is a schematic for navigating the hierarchy of setting items and for the sequence of operations
when selecting categories, setting values, etc.
Try out using the ENTER button, EXIT button, and touch ring while referring to the following.
Navigating the Hierarchy of Setting Items
Touch left or right or trace along the touch ring to directly select the setting value of the item
highlighted by the cursor ( ).
Touching the ENTER button brings up a list of options for the item highlighted by the cursor
( ), allowing you to select a setting value using the touch ring while viewing the list.
Indicates the currently displayed page/total
number of pages. You can turn the page by
touching the left or right of the touch ring.
The cursor ( ) indicates the currently
selected item.
You can move the cursor by touching the top or
bottom or by tracing along the touch ring.
The value at the position
changes
(or touch left or right)
Trace along the touch ring
Touch and hold the EXIT button (returns to

Top screen)

Top screen

Category list screen

List of values
Touch the EXIT button
Touch the EXIT button
Touch the
ENTER button
Touch the ENTER button

Casio Privia PX-S7000 Specifications

General

Touch Sensitivity	5 sensitivity levels, off
Sound Source	Multi-dimensional Morphing AiR Sound Source
Polyphony	256 notes
Key Action	Smart Hybrid Hammer Action Keyboard
Effects	Reverb, Chorus, DSP, Brilliance
Amplifiers	8W + 8W
Bluetooth	Yes (Audio & MIDI)
Pedals	3 (Damper, Soft, Sostenuto)
Display	LCD with backlight
USB Port	Yes (Type B)
Headphone Jack	2 (Stereo standard)
Dimensions	1340 x 242 x 102 mm (w/o stand, and music stand)
Weight	14.8 kg
Included Accessories	Music stand
Power Source	AC adapter
Number of Tones	400 built-in tones
