Overview and Setup
EN-20
Using headphones cuts off output from the built-in speakers, which means you can practice playing
even late at night without disturbing others.
• Be sure to turn down the volume level before connecting headphones to the PHONES jack.
• Do not listen to very high volume output over headphones for long periods. Doing so creates
the risk of hearing damage.
• When connecting headphones to the stereo mini phone jack, be sure to use a stereo mini
phone plug (Mini TRS phone). Use of other types of plugs is not supported.
• If you are using headphones that require an adaptor plug, make sure you do not leave the
adaptor plugged in when you unplug the headphones. If you do, nothing will sound from the
speakers when you play.
• Use commercially available headphones that meet the following conditions.
− Maximum input: 150mW or greater
− Impedance: 32Ω or greater
• Use of the optional CP-16 headphones is not recommended.
If “SYSTEM” > “Speaker Out” in the FUNCTION menu (page EN-33) is set to “On”, sound will come out
of the speakers even if headphones are plugged into either PHONES jack.
• The setting values and details for this are as follows:
Using Commercially Available Headphones
Outputting From the Speakers While Headphones are Connected
Setting value Description
Off The speakers do not output sound regardless of whether a plug is inserted into
the PHONES jack.
On The speakers output sound regardless of whether a plug is inserted into the
PHONES jack.
Auto When a plug is inserted into the PHONES jack, the Digital Piano’s speakers do
not output sound; when a plug is not inserted, the speakers output sound.
PHONES jacks
(Top: stereo mini phone jack (Mini TRS phone)/
Bottom: stereo standard phone jack (TRS phone))
To Next Page
