Casio Privia PX-S7000 User Manual

Playing Notes with Different Tones
EN-47
4. Perform the operation described in “Selecting a Single Tone” (page EN-41)
operation to select the lower range tone (Lower tone).
• To use both SPLIT and LAYER at the same time, perform steps 3 to 4 of the above operation
following the operation described in “Layering Two Tones” (page EN-44).
Under initial default settings, the lowest note of the upper range (called the split point) is F{3.
1. Select the “01 Standard” of the F button set. See “To change the F Button Set”
(page EN-32).
2. Touch and hold the F3 button (SPLIT).
The “SPLIT POINT” screen appears.
3. Press the keyboard key you want to be the split point (lowest note of the upper
range).
The note of the split point is changed to that of the key pressed.
• You can also change the split point using the touch ring or touching the ENTER button to
display a list of note names.
4. Touch the EXIT button to exit the setup.
1. Select the “01 Standard” of the F button set. See “To change the F Button Set”
(page EN-32).
2. Touch the F3 button (SPLIT) to turn off the indicator on the display.
Changing the Split Point
Unsplitting the Keyboard
Split point note

Casio Privia PX-S7000 Specifications

General

Touch Sensitivity	5 sensitivity levels, off
Sound Source	Multi-dimensional Morphing AiR Sound Source
Polyphony	256 notes
Key Action	Smart Hybrid Hammer Action Keyboard
Effects	Reverb, Chorus, DSP, Brilliance
Amplifiers	8W + 8W
Bluetooth	Yes (Audio & MIDI)
Pedals	3 (Damper, Soft, Sostenuto)
Display	LCD with backlight
USB Port	Yes (Type B)
Headphone Jack	2 (Stereo standard)
Dimensions	1340 x 242 x 102 mm (w/o stand, and music stand)
Weight	14.8 kg
Included Accessories	Music stand
Power Source	AC adapter
Number of Tones	400 built-in tones
