Casio TE-2200 Service Manual

— 1 —
1. SPECIFICATIONS
1-1. Electrical specifications
1-2. Environmental specifications
120 V 220 V 230 V 240 V
•Power consumption In operation Max. 0.5 A 0.25 A 0.25 A 0.25 A
stand-by Max. 0.1 A 0.05 A 0.05 A 0.05 A
•Memory protection Back-up battery Vanadium lithium battery
Except. USA, CANADA Back-up period 90 days (25 °C)
Battery life Replace the battery every 5 years.
Recharge time 48 hours (full charge)
•Memory protection Back-up battery Mangan battery (UM-3 × 3)
USA, CANADA Back-up period 1 years (25 °C)
Battery life Replace the battery every 1 years.
•Clock & Calendar Accuracy Within ± 30 sec. per month (25 °C)
Auto calendar Effective until 2099 A.D.
• Operating temperature 0 °C ~ 40 °C
• Operating humidity 10 % ~ 95 %
• Storage temperature -25 °C ~ 65 °C
• Storage humidity 10 % ~ 95 %
• Vibration strength 1.5 G (The machine must be in the carton box)
1-3. Main components
• CPU Name uPD784215AGC279
Number of control bit 16 bit
• RAM (US) Name M68AF128BM70 × 2
Capacity 1 Mbit
• RAM (EURO) Name M68AF511AM70
Capacity 4 Mbit
• Flash ROM Name MBM29F160BE90TN
Capacity 16 Mbit
• I/O controller Name uPD784215AGC280
• Themal printer Name FTP-628MCL518 (receipt)
FTP-628MCL518 (journal)
Print method Thermal dot line printing
Head specification Total dot number : 384 dots/dot line
Dot pitch : Length 8 dots/mm
Wide 8 dots/mm
Paper cut Manual-paper cut
• Roll paper Type Heat-sensitive paper
Size 57.5 ± 0.5 mm
Roll diam φ 80 or less
Thickness 0.06 ~ 0.085 mm

Casio TE-2200 Specifications

General

Types of payment	Cash
Supported paper width	58 mm
Display digits	10 digits
Second display	Yes
Second display type	LED
Display number of characters	16
Power source	AC
AC input voltage	120-230 V
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 85 %

Weight and Dimensions

Depth	450 mm
Width	400 mm
Height	277 mm
Weight	12000 g
