Casio TE-2200 Service Manual

— 41 —
[ 16 ] LCD CONTRAST ADJUSTMENT
[Function]
Adjust the contrast for LCD and then write the value into the FLASH.
FLASH can be written 16 times. Error occurs if it’s written more than 16 times. Clear the FLASH for
MASK DIAG and then set the IPL and LOCALE again to write after 16 times.
Contrast value is selected as same as the previous setting (“32” is selected for no setting).
Press “CA/AMT TEND” button to correct writing after adjustment.
[Operation]
Operation : 4 2 1 SUBTOTAL
Press buttons as follows to operate.
“DARK” button : contrast +1
“LIGHT” button : contrast -1
“CA/AMT TEND” button : Contrast determination (Write into Flash)
Contrast adjustment is completed.
“C” button : Stop adjusting
Turn off the power : Stop adjusting
[Pop-up display]
[Main display]
[PRINT]
3 4 5 X X
XX is the setting value.
ABCDEFGH I JKLMNOP
QRSTUVWXYZabcde f
12345 XX
XX is the setting value.
DISP 421
LCD CONTRAST XX
END 42 1
XX is the setting value.
LCD CONTRAST NG
LCD CONTRAST OVER
LCD CONTRAST ESC
It is printed if the error occurs.
It is printed if the flash is written more than 16 times.
It is printed if “C” key is depressed.

Casio TE-2200 Specifications

General

Types of payment	Cash
Supported paper width	58 mm
Display digits	10 digits
Second display	Yes
Second display type	LED
Display number of characters	16
Power source	AC
AC input voltage	120-230 V
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 85 %

Weight and Dimensions

Depth	450 mm
Width	400 mm
Height	277 mm
Weight	12000 g
