Casio TE-2200 Service Manual

— 36 —
[ 8 ] CF-CARD CLEAR WRITE/READ test
[Function]
This test will check the clear Åïwrite/read test for CF-CARD.
Perform the write/read test (connection check) after clearing all memory.
Note that this test does not ensure the data inside the CF-CARD as well as its performance.
[Operation]
Operation : 0 n 3 1 3 SUBTOTAL
n : 0 = One time check(can be omitted)
not 0 = Continuous check (To stop the test, press “C” key or turn off the power by rotating
the key.)
[PRINT]
NG and the address are printed if WRITE cannot be done
normally.
CF - CARD 313
CF CLR&WR OK
END 31 3
[ 9 ] Locale information write
[Function]
The Locale information is written into FLASH MEMORY.
[Operation]
Operation : x1 x2 0 0 1 6 SUBTOTAL
x1 : xcountry code, x2: SUB CODE
x1 x2: 10 R Europe, 20 R US, 30 R UK, 40 R Germany,
50 R Canada, 60 R Direct, 61 R Direct (Hebrew)
[PRINT]
The following receipt is not issued when commands other than x1, x2.
The following is printed when an error occurs during writing LOCALE.
| LOCALE NG |
The LOCALE can be written 5 times. When no more LOCALE can be written
(writing more than 5 times), the following is printed.
| LOCALE OVER |
LOCALE 0016
LOCALE OK
END 00 16
x1x2
x1x2

Casio TE-2200 Specifications

General

Types of payment	Cash
Supported paper width	58 mm
Display digits	10 digits
Second display	Yes
Second display type	LED
Display number of characters	16
Power source	AC
AC input voltage	120-230 V
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 85 %

Weight and Dimensions

Depth	450 mm
Width	400 mm
Height	277 mm
Weight	12000 g
