Casio TE-2200 Service Manual

— 92 —
TE-2400
N Item Code No. Parts Name S
p
ecification R
1. MAIN PCB Block
1 10204425 PCB ass'y / E443-1 RJE501482*002V01 1 1 DV A
1 10204427 PCB ass'y / E443-1 RJE501482*003V01 1 DU A
1 10204428 PCB ass'y / E443-1 RJE501482*004V01 1 1 DU A
35802371 Connector B4P-VH 1 1 1 1 1 AB X
30007917 D-SUB connector ID9P33E4GX28 2 2 2 2 2 AK X
10204414 Connector IMSA-9604S-28C 1 1 1 1 1 X
32402089 BUZZER PKM22EPTH2001-B0 1 1 1 1 1 AE X
10222619
Cr
y
stal oscillator C-002RX-8.3/10-LF 1 1 1 1 1
A
D
X
30007777 FUSE 230.600MXW 1 1 1 1 1 AE A
10196293 LSI D784215AGC279-8EUA 1 1 1 1 1 BK B
10214954 LSI D784215AGC290-8EUA 1 1 1 1 1 BK B
10197486 LSI MBM29F160BE90TNKE1 1 1 1 1 1 BC B
10127164 LSI M68AF511AM70MC6U 1 1 1 BN B
10204546 LSI M68AF127BM70MC6U 2 2 AX B
10196925 LSI MX23C1610MC10GSA02 1 AU B
10196316 LSI UPD65881MC1065A4-A 1 1 1 AT B
10204547 Monolithic IC LB1936V-TLM-E 2 2 2 2 2 AK B
10204548 IC XC6206P332PR 1 1 1 1 1 AD B
10127165 IC/Reset S-80123BNMC-JGIT2G 1 1 1 1 1 AI B
10146550 IC MAX3243CPWR 2 2 2 2 2 AW B
21120821 Monolithic IC BA10393F-E2 4 4 4 4 4 AB B
21120823 Monolithic IC BA12003BF-E2 1 1 1 AF B
10105416 IC/MOS SN74AHCT08PWR 1 1 1 1 1 AC B
10120128 IC/CMOS SN74AHCT244PWR 1 1 1 1 1 AC B
10120129 IC/CMOS SN74LV04APWR 2 2 2 2 2 AC B
10005659 IC/CMOS SN74LV08APWR 4 4 4 4 4 AB B
10120130 IC/CMOS SN74LV11APWR 1 1 1 AC B
10005669 IC/CMOS SN74LV139APWR 1 1 1 1 1 AD B
10207634 IC SN74LVC1G08DCKR 1 1 1 1 1 AB B
10005721 IC/CMOS SN74LV244APWR 1 1 1 1 1 AF B
10004413 IC/MOS SN74LV32APWR 2 2 1 1 2 AB B
10089475 IC SN74LV367APWR 2 2 2 2 2 AE B
10050431 IC/CMOS SN74LV373APWR 1 1 1 1 1 AI B
10005662 IC SN74LV374APWR 3 3 3 AF B
10105407 IC/CMOS SN74LVC244APWR 2 2 2 2 2 AA B
10210709 Switch SKQLLDE012 1 1 1 1 1 AF C
10146565 Ceramic Oscillator CSTCE12M5G52-R0 2 2 2 2 2 AK C
10204573 Connector 53398-0371 1 1 1 1 1 AD X
10204574 Connector 53398-1571 1 1 1 AH X
10204575 Connector B12B-ZR-SM4-TBLFSN 1 1 1 AF X
Connector B2B-ZR-SM4-TBLFSN 1 1 1 1 1 X
10204576 Connector B3B-PH-SM4-TBLFSN 2 2 2 2 2 AC X
10204578 Connector IMSA-9610S-20Y920 1 1 1 1 1 AG X
10204580 Connector IMSA-9610S-30Y920 2 2 2 2 2 AL X
10120086 Connector FCN-568H050-G/A3 1 1 1 1 1 BN X
2. Main Dis
p
la
y
Block
for except USA, Canada
2 10216505 LCD unit JIC-MSGF8857-07 1 1 1 CL A
3 10204335 E443-LCD assy RJE501486*001V01 1 1 1 CX A
10127161 LED NSPW312BS(B1B2-SR) 3 3 3 BD B
10120089 LED NSPG320BS(G-ST) 2 2 2 BI B
35012765 Connector S12B-ZR 1 1 1 AF X
10204339 Connector IMSA-9610S-20B-TC 1 1 1 AE X
10223031 IC LM2611BMF NOPB 1 1 1 AY B
10005659 CMOS IC SN74LV08APWR 1 1 1 AB B
21120823 Monolithic IC BA12003BF-E2 2 2 2 AF B
Q't
y
Price
Code
Europe UK USA Canada
Other
Countries

Casio TE-2200 Specifications

General

Types of payment	Cash
Supported paper width	58 mm
Display digits	10 digits
Second display	Yes
Second display type	LED
Display number of characters	16
Power source	AC
AC input voltage	120-230 V
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 85 %

Weight and Dimensions

Depth	450 mm
Width	400 mm
Height	277 mm
Weight	12000 g
