— 32 —
5-6. Operation of each test
[ 1 ] Batch test 1
[Function]
RAM test, test print, time setting, buzzer test and drawer open test are performed continuously.
[Operation]
Operation : 1 SUBTOTAL
[Print]
* Normal print
[ 2 ] Batch test 2
[Function]
Display test and backlight test are performed continuously.
The following tests are performed
automatically.
(1) RAM test: WRITE/READ area test.
(2) Test print
(3) Time setting: Set the following data.
Arranged data: 2005 December
31,23:59’30
(4) Buzzer: Ring once the one shot buzzer.
No print or display in this test.
(5) Drawer open: Drawer 1 opens only.
(6) Receipt issuance
[Pop-up display]
DIAG 1
00n
n
n=0 1 2 3 2 3
[Main display]
n=0 1 2 3 2 3
BATCH 1
RAM WR OK
BBBBBBBBBBBBBBBBBBBBBBBB
DATE 05/12/31
TIME 23 :59-30
DRW 1 OK
END 1
Print Test
* See “RAM test” if “ERROR” appears while
performing the RAM test.
[Operation]
Operation : 2 SUBTOTAL
The following tests are performed
automatically.
(1) Display test: Refer to “[12] Display test.”
Press any key to go to the next
test.(Same in the backlight test also)
Press any key to go on to the next test.
(Same in the backlight test also)
(2) Main test: Refer to “[15] LCD test.”
(3) Pop-up display test: Perform Pop-up
display test. See “[14]” for more
information.
(4) Backlight test: Refer to “[13]” for more
information.
Perform the backlight test.
The backlight color changes if any key is
depressed.
Refer to the “Backlight test” for details.
(5) Receipt issuance
[Print]
* Normal print
[Pop-up display]
Refer to each item.
[Main display]
Refer to each item.
BATCH 2
DISP OK
DISP MAIN OK
DISP 7SEG OK
BACK L I GHT OK
END 2
