Casio TE-2200 Service Manual

— 94 —
N Item Code No. Parts Name S
p
ecification R
25
10225548
Power cord X-AU10S3-LF 1 BB C
26 30304055 Ferrite core L5T18X6X10 1 1 1 1 1 AC X
27 10210667 PW case sub assy RJE501596*001V01 1 1 1 1 1 BL X
6. U
pp
er case Block
28 10224160 KB cover RJE501471-001V02 1 1 1 1 1 AU X
29 10203373 FK board RJE501456-002V01 1 1 1 1 1 AV X
30 10203345 FK switch RJE501472-001V01 11 11 11 AA C
31
10225057 FK plate RJE501514-006V02
11 1
A
VC
31
10225060 FK plate RJE501514-009V02
11
A
PC
32 10223217 Paper cutter RJE501069-001V01 1 1 1 1 1 AC C
10203349 Lens R RJE501460-001V01 1 1 1 AB X
10203350 Lens L RJE501461-001V01 1 1 AB X
33 10207408 E6 chassis RJE501453-001V01 1 1 1 1 1 AU X
34 10211505 Mode SW assy E341052*002V01 1 1 1 1 1 AV B
35
10210684 Blind J RJE501566-001V01
1 11 1 1
AA
X
PWB E443-E6 RJE501497D301-1 1 1 C
7. Switch board Block
36 10204331 E443-E6 assy RJE501485*002V01 1 1 1 AO A
PCB E443-E6 RJE501497D301-1 1 1 1
10204327 Switch SKHHALA010 5 5 5 AA C
10204328 Switch SKHHDAA010 6 6 6 AA C
10204329 LED HLMP1503 7 7 7 AA C
35022040 Connector 53048-1510 1 1 1 AD X
37 10210682 E6 cable sub assy RJE501493*001V01 1 1 1 AS C
8. Lower case Block
38 10203375 Lower case RJE501454-002V01 1 1 1 1 1 BS X
10210683 L-Chassis RJE501452-001V02 1 1 1 1 1 BL X
10210658 PCB spacer RJE501464-001V01 6 6 6 6 6 AA X
DRW cable sub assy RJE501492*2 1 1 1 1 1 C
39 10203347 CF cover RJE501458-001V01 1 1 1 1 1 AQ C
40 10203348 CN cover RJE501459-001V01 1 1 1 1 1 AQ C
41 10207409 CN chassis RJE501473-001V01 1 1 1 1 1 AJ X
42 10210663 FFC cable C RJE501553-003V01 1 1 1 1 1 AZ C
43 10210666 FFC cable D RJE501553-004V01 2 2 2 2 2 AF C
10211518 PCB spacer SPD-3U 4 4 4 4 4 AB X
10121158 Ferrite core FRS31x5x12 1 1 AG X
10211388 LED FG wire assy RJE501630*001V01 1 1 AD X
44 10204356 E443-PRN assy RJE501490*001V01 2 2 2 2 2 AP B
54300207 NUT SB-3001 2 2 2 2 2 AA X
9. Printer Block
45 10212617 Thermal printer FTP-628MCL518#65 2 2 2 2 2 CP A
10210645 Caution plate RJE501570-001V01 2 2 2 2 2 AE X
46 10203342 PR mount RJE501470-001V01 1 1 1 1 1 AV X
47 10210042 R/P roller E411696-001V02 2 2 2 2 2 AA B
48 10078724 Platen arm R E140474-1 1 1 1 1 1 AK C
49 10072642 Platen arm J E140472-1 1 1 1 1 1 AM C
50 10211978 Motor assy RJE501529*001V01 1 1 1 1 1 AZ B
51 10211981 Shaft Journal RJE501568-001V01 2 2 2 2 2 AK X
52 10224761 Battery ass'y RJE501528*001V02 1 1 1 BP A
53 10110555 Battery Cover RJE500211-002V01 1 1 1 AB B
53 10110554 Battery cover RJE500211-001V01 1 1 AC B
63224499 Battery spring A-G55 A42606-1 1 1 AA C
60006091 Battery spring G67 A43656-1 1 1 AA C
60207658 Battery spring B-1G513 P408A-1 1 1 AB C
60207666 Battery spring B-2G514 P409A-1 1 1 AA C
10211983 Battery cable sub assy RJE501491*001V01 1 1 AB C
Q't
y
Price
Code
Europe UK USA Canada
Other
Countries

Casio TE-2200 Specifications

General

Types of payment	Cash
Supported paper width	58 mm
Display digits	10 digits
Second display	Yes
Second display type	LED
Display number of characters	16
Power source	AC
AC input voltage	120-230 V
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 85 %

Weight and Dimensions

Depth	450 mm
Width	400 mm
Height	277 mm
Weight	12000 g
