Casio TK-6500 User Manual

N Item Code No. Parts Name Specification Q'ty Price code R
USA, Canada
R13, 15, 18-21, 25, 61 RESISTOR/CHIP RC1608-102-J-T 8 X
R14 RESISTOR/CHIP RC1608-222-J-T 1 X
R2 RESISTOR/CHIP RC1608-154-F-T 1 X
R23 RESISTOR/CHIP RC1608-563-F-T 1 X
R24, 44 RESISTOR/CHIP RC1608-472-F-T 2 X
R26 RESISTOR/CHIP RC1608-104-J-T 1 X
R27 RESISTOR/CHIP MCR03EZHF3600 1 X
R28 RESISTOR/CHIP MCR03EZHF1540 1 X
R3 RESISTOR/CHIP MCR50JZH-J-202 1 X
R32 RESISTOR/CHIP RC1608-334-J-T 1 X
R33 RESISTOR/CHIP RC1608-105-J-T 1 X
R38 RESISTOR/CHIP RC1608-432-F-T 1 X
R39 RESISTOR/CHIP RC1608-622-F-T 1 X
R4, 16, 29, 42, 56-58,
63, 64, 72, 74, 83, *3
RESISTOR/CHIP RC1608-103-J-T 13 X
R40 RESISTOR/CHIP RC1608-123-F-T 1 X
R5, 62, 69 RESISTOR/CHIP RC1608-101-J-T 3 X
R59 RESISTOR/CHIP RC1608-822-J-T 1 X
R6 RESISTOR/CHIP RC1608-202-J-T 1 X
R60, 68 RESISTOR/CHIP RC1608-563-J-T 2 X
R7 RESISTOR/CHIP RC1608-623-J-T 1 X
R70 RESISTOR/CHIP MCR18EZHJ102 1 X
R71, 75-78 RESISTOR/CHIP RC1608-331-J-T 5 X
R8 RESISTOR/CHIP RC1608-332-J-T 1 X
R9 RESISTOR/CHIP MCR50JZHJ222 1 X
PCB ASSY/E475-1-M E240579*3 1 X
PCB/E475-1 E240581-1 1 X
2. Main Display block
2 61935012 PCB ASSY/E445A-E2 E340792*1 1 DC B
IC1, 2, 3 21120823 IC/MOS BA12003BF-E2 3 AF A
IC4 10003984 IC/MOS SN74LV00APWR 1 AB A
IC5, 6, 10 10003982 IC/MOS SN74LV165APWR 3 AE A
IC7, 8, 9 20061703 LSI LC7932M-TE-R 3 AP A
FB1-30 30450028 INDUCTOR BK1608HS601-T 30 AA B
LED1-10 24088398 LED GL8EG42 10 AA B
LED11-15 23201365 LED HDSP-5621#S02 5 AP B
Q1-5 22501603 TRANSISTOR 2SB1182TLQR 5 AC B
N
CA1-6 28073624 CAPACITOR/MODULE MNA145A101KK 6 AA C
CN1 35405185 CONNECTOR HFW12S-2STE1 1 AB C
CN2 35405184 CONNECTOR HFW10S-2STE1 1 AB C
CN3 35017728 CONNECTOR B14B-PHDSS 1 AB C
CN4 35405190 CONNECTOR SFW27R-5STE1 1 AE C
CN5 35405196 CONNECTOR HFW9R-1STE1 1 AB C
CN6 35405186 CONNECTOR HFW24R-1STE1 1 AD C
N
RA1-9 26523056 RESISTOR/CHIP NETWORK MNR34J5ABJ121 9 AA C
N
RA10, 25-27 26601174 RESISTOR/CHIP NETWORK RAC1608-3314DJT 4 AA C
N
RA11, 19, 22, 23, 28,
26601156 RESISTOR/CHIP NETWORK RAC1608-1034DJT 6 AA C
N
RA12-17, 24 27975519 RESISTOR/CHIP NETWORK RAC1608-1024DJT 7 AA C
N
RA18, 20, 21 27975518 RESISTOR/CHIP NETWORK RAC1608-1014DJT 3 AA C
N 62481456 HOLDER/LED F E445 E340718-1 1 AF C
C1-7 CAPACITOR/CHIP TMK107F104ZZ-T 7 X
C8-10 CAPACITOR/CHIP UMK107CH101JZ-T 3 X
R1, 3, 5, 7, 9 RESISTOR/CHIP RC1608-471-J-T 5 X
R11, 12 RESISTOR/CHIP RC1608-121-J-T 2 X
R13 RESISTOR/CHIP RC1608-563-J-T 1 X
R14, 15 RESISTOR/CHIP RC1608-331-J-T 2 X
R2, 4, 6, 8, 10, 16, 17 RESISTOR/CHIP RC1608-103-J-T 7 X
PCB/E445A-E2 E340789A-1 1 X
3. Customer Display block
N
3 43081401 PCB/E445B-E2-2 E340800-1 1 AF X
23201365 LED HDSP-5621#S02 4 AP B
24088398 LED GL8EG42 2 AA B
N
4 35405193 CONNECTOR HLW10R-2C7 1 AB C
N
5 35405194 CONNECTOR HLW12R-2C7 1 AB C
6 62481475 CABLE/FFC JOINT E440657-4 1 AU C
7 62481476 CABLE/FFC JOINT E440657-5 1 AU C
8 62481785 CASE/REAR DISPLAY E240511A-1 1 AH C
9 62481679 PLATE/REAR DISPLAY E240512-3 1 AH B
N 62481566 HOLDER/LED R E445 E440663-1 1 AA C
N
10 62481698 PLATE/INSULATION E440781-1 1 AB C
WIRE/JUMPER UJW-C(10MM) 5 AA X
WIRE/JUMPER UJW-D(12.5MM) 3 X
WIRE/JUMPER UJW-E(15MM) 3 X
WIRE/JUMPER UJW-J(25MM) 1 X
4. Button block
N
11 62481752 FPC E240553A-1 1 BJ B
N
12 10007163 RUBBER/CONTACT E240587-1 1 BI B
N
13 62481723 SHEET/COMMON E340810-1 1 AX B
N
14 62481724 SPACER/E577 E340811-1 1 AH C
N
15 62481726 CHASSIS/KEYBOARD E340812-1 1 AT X
N
16 62481722 FRAME/KEYBOARD E140283-1 1 BB X
N
17 62214932 SHEET E311590-1 1 AW X
N
18 62481742 PLATE/MODE KEY E340735A-16 1 AG C
COVER/SHEET WT-62 (SALES ITEM) E240303-1 1 X
- 88 -
