N Item Code No. Parts Name Specification Q'ty Price code R
USA, Canada
CLIP CS-4U 1 X
CONTACT 1561T 3 X
CONTACT SPH-002T-P0.5S 3 X
HOUSING PHR-3 1 X
HOUSING 1625-03R1 1 X
HOUSING 51065-0200 1 X
INSERT/BIT SB-3001 3 X
LABEL/CONNECTOR E475 E440764-2 1 X
SCREW 3X5 ZMC 2 X
SCREW 3X8 ZMC-3 2 X
SCREW 3X12 ZMC-3. 4 X
TAPE 140MMX15MM 1 X
TERMINAL 50212-8000 2 X
TUBE/UL NO.22 1 X
WIRE AWG#26 UL1007 3 X
WIRE AWG#28 UL1007 2 X
9. Printer block
56 10003971 PRINTER/DIGITAL M-U420-061 1 DQ A
57 10017754 CORE/FERRITE SSC-50-12 1 AG C
N
58 10017703 WIRE SUB ASSY/FG E441049*1 1 AA C
N
59 62481652 CUSHION E440661-1 2 AA X
N
60 62481650 CUSHION E440660-1 1 AA X
N
61 62481651 CUSHION E440659-1 1 AA X
10. Others
62 62481688 KEY SET SUB ASSY E340769*2 1 AS B
62A 62481755 CONNECTOR SUB ASSY/PHDR E440716A*1 1 BD C
62B 36375228 CORE/FERRITE TFC-20-10-10 1 AU C
CONTACT SPHD-001T-P0.5 28 X
HOUSING PHDR-14VS 2 X
TERMINAL SRA-51T-4 2 X
WIRE AWG#26 UL1007 14 X
63 62481561 COVER/L CONNECTOR E340773-1 1 AC C
64 62481269 COVER/REAR CONNECTOR E140255-1 1 AK C
65 10004831 LOCK ASSY/CYLINDER E340842*1 1 AT C
FRAME/CYLINDER E311847-1 1 X
PLATE/CYLINDER E311848-1 1 X
SHAFT/CYLINDER E311846-1 1 X
66 62465000 KEY SUB ASSY/CYLINDER E412062*1 1 AG C
N 62481471 PLATE/NAME E440654-1 1 AD C
N 62481684 SPACER/UPPER E440780-1 1 AE C
MENU/SHEET E340844A-2 1 X
MENU/SHEET
E340844A-4
1 X
PIN/SPRING 2X5 1 X
PLATE/RATING E340890-2 1 X
PLATE/SLIDE E440685-1 1 X
PROGRAM/SHEET
E340844A-5
1 X
SCREW 4 1 X
N
67 62480865 SCREW E440564-1 2 AA X
68 51501062 SCREW 3X8.... 3 AA X
N
69 54400558 SCREW 4X69 ZMC-3 1 AA X
TIE/INSULOCK T-18S 1 X
11. OPTION BOARD I/O PB-14
N Item Code No. Parts Name Specification Q'ty
Price code
R
USA, Canada Code
I/O PB-14 ARCNET BOARD
N 10006022 PCB/E475-ARC E340943-1 1 AL B
F1,2 30008079 FUSE 430.500 2 AD A
IC1 10006024 LSI COM20019ILJP 1 CF A
IC2 21120802 IC SN74LV373APWT-EL 1 AF A
IC3 21120801 IC SN74LV32APWT-EL 1 AB A
IC4 21056442 IC SN751178NS-EL 1 BJ A
X1 10006030 LOCK/CERAMIC CSTCV20.00MXJ040-T 1 AD A
D1-4 30007959 DIODE 1SS376TE-17 4 AA B
ZD1 23153115 DIODE PTZTE-255.1B 1 AB B
N C6 28073647 CAPACITOR/ELECTROLYTIC RV2-16V101MS-R 1 AA C
CN1 10005643 CONNECTOR HFW28S-2STE1 1 AD C
CN2 77401603 CONNECTOR B2B-PH-SM3-TB 1 AC C
N RA1 10006028 RESISTOR/MODULE RAC1608-5624DJT 1 AA C
N RA2-4 10005641 RESISTOR/MODULE RAC1608-4704DJT 3 AA C
C1,2,4,7 28073629 CAPACITOR/CHIP TMK107F104ZZ-T 4 AA X
N C3 28073631 CAPACITOR/CHIP UMK107CH101JZ-T 1 AA X
N C5 28073627 CAPACITOR/CHIP TMK107B102KZ-T 1 AA X
R1 27953605 RESISTOR/CHIP MCR03EZHJ471 1 AA X
R10,11,14,15 27953479 RESISTOR/CHIP MCR03EZHJ100 4 AA X
R12,13 27952940 RESISTOR/CHIP MCR03EZHJ102 2 AA X
R2-4 27952926 RESISTOR/CHIP MCR03EZHJ101 3 AA X
R5 27953542 RESISTOR/CHIP MCR03EZHJ562 1 AA X
R6,7 27953528 RESISTOR/CHIP MCR03EZHJ470 2 AA X
R8,9 27954368 RESISTOR/CHIP MCR03EZHJ203 2 AA X
62477372 PLATE/EARTH for In-Line cable E440398-1 2 AB
C
35005820 CONNECTOR KIT/INLINE XLP-KIT-1 1 AM
C
N 62464600 RESISTOR SUB ASSY E411305A*2 1 AG
C
62482218 CABLE/FFC JOINT (ARCNET board) E440657-7 1 AA
C
10005683 CONNECTOR SUB ASSY/INLINE E440720*2 1 AF
C
- 90 -
